/ Product catalogue / Commercial and industrial ventilation / Inline fans / For round duct / Centro-MZ EC / Centro-MZ EC 315
| Unit of measurement | Centro-MZ EC 315 | |
| Connected air duct size | mm | 315 |
| Phases | - | 1 |
| Minimum supply voltage | V | 230 |
| Maximum supply voltage | V | 230 |
| Power supply frequency | Hz | 50/60 |
| Rated power | W | 164 |
| Unit current | A | 1.25 |
| Maximum airflow | m³/h | 1370 |
| Rotation speed at 50hz | - | 3588 |
| Sound pressure level LpA at 3 m | dB(A) | 49 |
| Weight | kg | 5.3 |
| Transported air temperature (max) | °С | 60 |
| Transported air temperature (min) | °С | -25 |
| Ingress protection rating | - | IPX4 |
| Impeller material | - | Plastic |
| Ø D | Ø D1 | H | L | L1 | L2 |
|---|---|---|---|---|---|
| 313 | 405 | 460 | 245 | 25 | 30 |
